Inside OrCAD Capture

This book takes the reader step by step through the design capture process using OrCAD's Capture for Windows. Examples of increasing complexity move the reader from tool basics through advanced techniques that increase productivity. Tips and suggestions are presented throughout the book to help the user avoid common design pitfalls and work toward efficient design capture practices. The companion disk includes exercise files. Written to Release 7.2.
