Machine Devices and Components Illustrated Sourcebook

Designed for on-the-job use, this exhaustive sourcebook spans the entire range of mechanical design from standards tables to class analytical methods

Over 2000 drawings of a broad selection of mechanical components and assemblies found in home appliances, office machines, vehicles, aircraft, ships, construction and factory equipment, and machine tools.

Provides the most commonly used design formulas as well as additional structural data.
